TIFTM070-11 is a soft silicone putty thermal gap filler,which blend with
exclusiveformula,that offer superior thermal performance, and
compressibility.Due to TIFTM070-11 is made by high vicosity silicon oil ,that can prevent
thermalformula seprate from it.Besides ,compared with traditionally
thermal pad, it cancontrol bonded shifiting issue much better.
TIF070-11-silicone-putty-thermal-gap-filler.pdf
TIFTM070-11 operation mold is simliar as grease ,such as silkprint and screen
printor automatic injected facility.TIFTM070-11 can be applied on chip micro processor,PPGAs,Micro BGApackage,BGA
package,DSP chip,LED lighting and other high power
electriccomponent.
Feature
>Thermal conductivity
>Soft, very low compression
>Low thermal inpedance
>Operate automaticly
>Proven long-term reliability
Application
>Heat-sink & frame
>LED backlight module,LED lighting
>High speed hardware driver
>Micro heat pipe
>Vihicel enginee controler
>Telecom industry
>Semiconductor 'automatic laboratory equipment.
| TIFTM070-11 Property |
| Color | Gray | Visual |
| Construction & Composition | Ceramic filled silicon material | ********** |
| Viscosity | 21280000 cps | GB/T 10247 |
| Specific Gravity | 3.50 g/cc | ASTM D297 |
| Thermal conductivity | 7.0 W/mK | ISO 22007-2 |
| Thermal diffusivity | 2.80 mm2/s | ISO 22007-2 |
| Specific heat capacity | 2.70 MJ/m3K | ISO 22007-2 |
| Continuous Use Temperature | -40 ~150°C | ****** |
| Dielectric breakdown strength | 200 V/mil | ASTM D149 |
| Flame Rating | 94V0 | E331100 |
Packing details
30 cc/pc, 98 pc/box; 300 cc/pc 6 pc/box
We offer the custom packaged in syringes for automated despensing
applications.
Please contact us for confirming.
